PLC System Plain-Moving Type Mechanical Parking Equipment / Auto
Parking Lift
380V 3-Phase 5- Wire Plain Moving Warehouse PLC Car Parking Lift
Equipment
Equipment introduction
Plane mobile parking equipment refers to mechanical parking
equipment that moves vehicles on the same floor with a moving
trolley or crane plane or traverses the plane of the vehicle board
to access the parked vehicles.
working principle
The lift of the plane mobile mechanical parking equipment is
vertically lifted and moved from the entrance handling vehicle to
different levels, and then the carrier transports the vehicle along
the track in the passage to each parking space or the vicinity of
the elevator at a high speed, and the access exchange mechanism of
the carrier is used. The vehicle is exchanged between the carrier
and the parking space, or between the carrier and the elevator to
complete the access process.
Features and advantages
Lifting and traversing simultaneously, minimizing warehousing time.
Increase parking space according to site size.
Advanced electrical control devices to save energy.
| Car Type | Car Type | D Type | T Type |
| Car size(mm) | Lenght*Width*Height |
| L5000*W1850*H1550 | L5300*W1900*H1550 |
| Car Weight | ≤2000kg | ≤2350kg |
Space Demand | Motor | Lifting mator | 18.5-30kw |
| Transverse motor | 2.2-3.0kw |
| Car board conveying motor | 1.5kw*2 |
| Car board grab motor | 0.4-0.75kw |
| Specification | Speed | Lifting speed | ≤60m/min |
| Transverse speed | ≤90m/min |
| Car board conveying speed | ≤32m/min |
| Car board grab speed | ≤8m/min |
| Operation Model | Touch Screen |
| Control System | PLC |
| Power Demand | 380V 3- -Phase 5-Wire |
| Entrance & Exit | Auto Door |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements.
Configuration is not only for wire rope and rated load, but also
considered the size of the traction, as a result, the tensile
strength of wire rope is greater than the weight of the lift. The
safety factor is equipped with more than four wire rope. So it
won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator
running?
If it occurs, the elevator will automatically stop due to the
electrical and mechanical safety device. In case of power
failure,elevator brakes will automatically taken. In addition, the
power supply departments such as planned outage, prior notice are
also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of
elevator will automatically restart without any danger. With anti
clamping switch, once the gate touched, this switching action make
the elevator unable to be closed and even reopened. In addition,
closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the
(tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily
proportional to the operation complexity. Therefore, escalators
designed by us apply an integrated structure, so that the equipment
is more precise and more efficient and allows easier and more
convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
