PAWO F10 Gustav Wolf Elevator Wire Rope Bending Resistance

Ask Lasest Price
Brand Name :	SUNNY
Model Number :	PAWO F10
Certification :	CE,ISO9001
Price :	$0.5~5meter
Payment Terms :	Western Union, T/T, L/C,Paypal
Supply Ability :	100000 meters/ Month
Delivery Time :	7 working days

Add to Cart

Product Details
Company Profile

PAWO F10 Gustav Wolf Elevator Wire Rope Bending Resistance

PAWO F10 Elevators Gustav Wolf Wire Rope With An Increased Bending Resistance

Special full steel rope with 9 outer strands

Our specially developed PAWO F10 is for the most demanding elevator installations. The rope´s 9 strand construction allows a tight fit of the rope in the groove.

Thus, this rope offers an extremely long service life, combined with an increased bending resistance. The compact structure of the core offers additional metallic cross-section.

Properties:

high rise
high number of bending cycles
heavy usage
low stretch
long service life

Construction: full steel rope with 9 strands, regular lay,

Technical terms of delivery to DIN EN 12385, ISO 4344

load bearing wires in the outer strands:

< 12 mm = 117

> 12 mm = 144

tensile grade 1570 N/mm2, steel wire bright or galvanized

Properties

Low and mid-rise
small to intermediate number of bending cycles
normal to heavy usage levels
wear-resistant
low elongation
extended service life

Technical data

Construction: 8 x 19 Seale with steel-reinforced fiber core, regular lay,

Technical terms of delivery to DIN EN 12385, ISO 4344

Load-bearing wires in the outer strands: 152 Tensile grade 1570 N/mm², steel wire bright or galvanized

Technical data

rope-Ø (permissible tolerance)
no load:	with load (10% of Fmin):
max. 3% < 10 mm	min. -1% <= 10 mm
max. 2% > 10 mm	min. -1% > 10 mm

rope diameter(mm)	calculated mass (kg/m)	min. breaking load (kN)	part-no.
8	0,270	43,2	721208032
9	0,340	54,8	721209032
10	0,420	67,2	721210032
11	0,503	80,2	721211032
12	0,600	95,6	721212032
13	0,707	113,4	721213032
14	0,850	135,7	721214032
15	0,950	152,8	721215032
16**	1,080	174	721216032
18*	1,410	219,7	721218032
19***	1,510	244,9	721219032
20*	1,700	272,5	721220032

9,5(3/8")	0,380	60,5	721209530
12,7(1/2")	0,680	109,5	721212730
17,5(11/16")	1,300	208	721217530

PAWO F10 Gustav Wolf Elevator Wire Rope Bending Resistance

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
