IP22 Classification Elevator Lift Motor For Elevator Door Opener Device Parts

Ask Lasest Price
Brand Name :	SUNNY
Model Number :	Motor for Door Operator
Certification :	CE,ISO9001
Price :	$50~200
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	5000pcs/month
Delivery Time :	7~15 days

Add to Cart

Product Details
Company Profile

IP22 Classification Elevator Lift Motor For Elevator Door Opener Device Parts

Motor for Elevator Door Operator Parts

Motor for Door Operator

1. The motor is compact in structure, small in size and light in weight.
2. The use of high-precision reduction gear effectively reduces noise and improves motor life
3. Precise positioning by hall induction.
4. Large transmission ratio design, large torque, high overload capacity.
5. The stator adopts paint dropping process to improve the insulation performance of the motor.
6. With mechanical self-locking function.

PARAMETER

Model		BL422445-PG4290S
Dimensions(mm)		Φ42x156	Rated Voltage(V)	24	Rated Current(A)	1.0
Rated Wattage(W)		8	Rated Torque(N·m)	5.0	Rated Speed(rpm)	15
Poles		12	Working Type	40%(S3 on 6s off 9s)	Classification	IP22
Insulation Grade		F	Encoder Classification	F
Pulley	Tooth Outline	5M
	Tooth Number	28
	Width of pulley(mm)	17

Drawing

Motor for Door Operator
Features:

1. The external rotor structure of the motor has high torque density.
2. The motor adopts enclosed structure and the protection level reaches IP65.
3. Optimizing the electromagnetic design to make the motor have smaller slot torque,stable operation at low speed and high eficiency.
4. Using high performance permanent magnet material, design overload capacity (≥250%)
5. The military grade electronic components was used in encoder for higher impact resistance.
6. The lead wire adopts silicon rubber high temperature shielded wire, which has good high temperature resistance and anti-interference ability.
7. Class-F Insulation Level, Make Motor Have Higher Life.
8. Compact structure design can further reduce the overall size of door operator.

PARAMETER

Model		PM5182022
Dimensions(mm)		140x160x64	Rated Voltage(V)	36	Rated Current(A)	1.9
Rated Wattage(W)		43	Poles	20	Rated Torque(N·m)	2.3
Rated Speed(rpm)		180	Rated Frequency(Hz)	30	Working Type	40%(S3 on 6s off 9s)
Classification		IP65	Insulation Grade	F	Encoder Classification	A/B/C/D/E
Pulley	Tooth Outline	5M
	Tooth Number	28/19/16
	Width of pulley(mm)	17/13
A		64
B		53
C		31
Note:		1.Installation size:140x120mm 2.Matching pulley:HTD5M-16,HTD5M-26,HTD8M-22 3.High efficiency, multi-directional installation, dustproof and oil proof, high temperature resistance, long life, F grade insulation grade, IP65 protection grade 4.Insulation Resistance≥100MΩ(Cold) 5.The whole machine pressure resistance 1500V, 1min without flashover, no breakdown 6.No-load noise value≤48dB 7.No-load level & vertical vibration≤0.45mm/s

Drawing

IP22 Classification Elevator Lift Motor For Elevator Door Opener Device Parts

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
